Mandatory Traffic Signs | Regulatory Signs Supplier & Exporter
MoRTH Compliant | IRC:67-2012 Compliant | Stop, Speed Limit, No Entry Signs
Mandatory traffic signs are the signs road users are legally required to obey — the stop sign, give way, speed limit, no entry and the prohibitory signs defined under IRC:67-2012. TMR Traffic Safety supplies and exports the complete range of regulatory signs, sourced from trusted manufacturers, using high-quality retroreflective materials. Our mandatory signs ensure 24/7 visibility and strict compliance with road safety standards worldwide. See where they fit among the four types of traffic signs.
Mandatory Traffic Signs — Complete Regulatory Range
Mandatory traffic signs are mostly circular with a red border, except the octagonal red stop sign and the inverted-triangle give way sign. TMR supplies every type below in 600mm, 750mm and 900mm sizes to IRC:67-2012.
Stop Sign
Octagonal - Red Background
The stop sign is an octagonal red board with the word STOP in white, and it requires drivers to come to a complete halt before proceeding.
Specifications
- • Sizes: 600mm, 750mm, 900mm
- • Material: Aluminium or ACM 1.0-2.0mm
- • Reflective: 3M Type III EG / Type IV HIP
Applications
Give Way Signs
Inverted Triangle - Red Border
Give way signs indicate that drivers must yield to traffic on the major road ahead.
Specifications
- • Sizes: 600mm, 750mm, 900mm
- • Design: White with red border
- • Compliance: IRC:67-2012
Applications
Speed Limit Signs
Circular - Red Border
Speed limit signs display the maximum legal speed for a particular road section.
Specifications
- • Sizes: 600mm, 750mm diameter
- • Custom speeds available
- • Materials: Aluminium or ACM
Applications
No Entry Signs
Circular - White Background
The no entry sign prohibits vehicles from entering a restricted area or road.
Specifications
- • Sizes: 600mm, 750mm diameter
- • White bar on blue background
- • Variants available
Applications
One Way Signs
Rectangular - Blue Background
One way signs indicate that traffic flows only in the direction shown by the arrow.
Specifications
- • Sizes: 600x450mm, 750x600mm
- • White arrow on blue
- • High visibility
Applications
Prohibitory Signs
Circular Variants
Complete range of prohibition signs including No Parking, No U-Turn, No Horn, and more.
Specifications
- • Circular design
- • Red border standard
- • Custom variants
Applications
Prohibitory Signs Range
Complete range of prohibition signs for traffic control and regulation enforcement
Technical Specifications & Standards
IS:67-2013 and IRC:67-2012 compliant specifications for regulatory signs
Standard Sizes (as per IRC:67-2012)
| Sign Type | Size (mm) | Application |
|---|---|---|
| Stop Sign (Octagonal) | 600mm | Urban/local roads |
| Stop Sign (Octagonal) | 750mm | State highways |
| Stop Sign (Octagonal) | 900mm | National highways |
| Circular Signs | 600mm | Urban/local roads |
| Circular Signs | 750mm | State highways |
| Circular Signs | 900mm | National highways |
| Rectangular Signs | 600x450mm | Urban roads |
| Rectangular Signs | 750x600mm | Highways |
| Triangular Signs | 600mm | Urban roads |
| Triangular Signs | 900mm | National highways |
Retroreflective Classes
| Class | Type | Reflectivity | Warranty | Application |
|---|---|---|---|---|
| 3M Type III | Engineering Grade | 70-100 cd/lx/m² | 5-7 years | Low-traffic roads |
| 3M Type IV | High Intensity Prismatic (HIP) | 250 cd/lx/m² | 7-10 years | State highways |
| 3M Type IV | High Intensity Prismatic (HIP) | 300 cd/lx/m² | 7-10 years | High-speed roads |
| 3M Type XI | DG Cube (Diamond Grade) | 400+ cd/lx/m² | 10-12 years | Expressways |
| 3M Type XI | Fluorescent | 600+ cd/lx/m² | 12+ years | Critical zones |
Base Materials
| Material | Thickness | Best For |
|---|---|---|
| Aluminium 1050/3105 | 1.0mm - 3.0mm | Standard road signs |
| Aluminium Composite Material (ACM) | 3mm - 4mm | Large signs |
| Mild Steel (GI/Color Coated) | 1.6mm - 3.15mm | Heavy-duty applications |
| Stainless Steel 304 | 1.0mm - 2.0mm | Premium/corrosion-prone areas |
Color Specifications
| Color | Pantone Reference | Usage |
|---|---|---|
| Red | 485 C | Stop, prohibition borders |
| Blue | 2945 C | Mandatory signs background |
| Yellow/Golden | 116 C | Warning elements |
| White | - | Text, symbols, backgrounds |
| Black | - | Symbols, text |
| Green | 348 C | Directional signs |
Indicative Pricing (per sign)
*Bulk order discounts available for quantities above 50 units
| Sign Type | Standard Size | 3M Type III Engineering Grade | 3M Type IV HIP | 3M Type XI DG Cube |
|---|---|---|---|---|
| Stop Sign | 600mm | ₹450-550 | ₹750-900 | ₹1,200-1,500 |
| Speed Limit | 600mm | ₹400-500 | ₹650-800 | ₹1,000-1,300 |
| No Entry | 600mm | ₹400-500 | ₹650-800 | ₹1,000-1,300 |
| Give Way | 600mm | ₹400-500 | ₹650-800 | ₹1,000-1,300 |
| One Way | 600x450mm | ₹450-550 | ₹700-850 | ₹1,100-1,400 |
Frequently Asked Questions
Find answers to common questions about our regulatory signs
Mandatory traffic signs are the road signs a driver is legally obliged to obey, defined under IRC:67-2012 and IS:67-2013. They include the stop sign, give way, speed limit, no entry, one way, no parking, no U-turn, no overtaking and no horn signs. Most are circular with a red border on a white background; the stop sign is octagonal and red, and the give way sign is an inverted white triangle with a red border. TMR Traffic Safety supplies all of these in 600mm, 750mm and 900mm sizes on Aluminium or Aluminium Composite Material (ACM) with 3M Type III Engineering Grade, Type IV High Intensity Prismatic (HIP) or Type XI DG Cube (Diamond Grade) retroreflective sheeting, screen printed and Electro-Cut films as per standard colour.
