Regulatory Signs & Mandatory Traffic Signs Manufacturer
MORTH Compliant | IRC:67-2012 Certified | Stop, Speed Limit, No Entry Signs
TMR Traffic Safety manufactures complete range of regulatory signs using high-quality retroreflective materials. Our mandatory signs ensure 24/7 visibility and strict compliance with Indian road safety standards.
Complete Range of Regulatory & Mandatory Signs
High-visibility signs engineered for durability and compliance with IRC:67-2012 standards
Stop Signs
Octagonal - Red Background
The universally recognized octagonal stop sign commands drivers to come to a complete halt before proceeding.
Specifications
- • Sizes: 600mm, 750mm, 900mm
- • Material: Aluminum Alloy 1.0-2.0mm
- • Reflective: Engineering / High Intensity
Applications
Give Way Signs
Inverted Triangle - Red Border
Give way signs indicate that drivers must yield to traffic on the major road ahead.
Specifications
- • Sizes: 600mm, 750mm, 900mm
- • Design: White with red border
- • Compliance: IRC:67-2012
Applications
Speed Limit Signs
Circular - Red Border
Speed limit signs display the maximum legal speed for a particular road section.
Specifications
- • Sizes: 600mm, 750mm diameter
- • Custom speeds available
- • Materials: Aluminum, MS, ACP
Applications
No Entry Signs
Circular - White Background
The no entry sign prohibits vehicles from entering a restricted area or road.
Specifications
- • Sizes: 600mm, 750mm diameter
- • White bar on blue background
- • Variants available
Applications
One Way Signs
Rectangular - Blue Background
One way signs indicate that traffic flows only in the direction shown by the arrow.
Specifications
- • Sizes: 600x450mm, 750x600mm
- • White arrow on blue
- • High visibility
Applications
Prohibitory Signs
Circular Variants
Complete range of prohibition signs including No Parking, No U-Turn, No Horn, and more.
Specifications
- • Circular design
- • Red border standard
- • Custom variants
Applications
Prohibitory Signs Range
Complete range of prohibition signs for traffic control and regulation enforcement
Technical Specifications & Standards
IS:67-2013 and IRC:67-2012 compliant specifications for regulatory signs
Standard Sizes (as per IRC:67-2012)
| Sign Type | Size (mm) | Application |
|---|---|---|
| Stop Sign (Octagonal) | 600mm | Urban/local roads |
| Stop Sign (Octagonal) | 750mm | State highways |
| Stop Sign (Octagonal) | 900mm | National highways |
| Circular Signs | 600mm | Urban/local roads |
| Circular Signs | 750mm | State highways |
| Circular Signs | 900mm | National highways |
| Rectangular Signs | 600x450mm | Urban roads |
| Rectangular Signs | 750x600mm | Highways |
| Triangular Signs | 600mm | Urban roads |
| Triangular Signs | 900mm | National highways |
Retroreflective Classes
| Class | Type | Reflectivity | Warranty | Application |
|---|---|---|---|---|
| Type I | Engineering Grade | 70-100 cd/lx/m² | 5-7 years | Low-traffic roads |
| Type III | High Intensity | 250 cd/lx/m² | 7-10 years | State highways |
| Type IV | High Intensity | 300 cd/lx/m² | 7-10 years | High-speed roads |
| Type V | Diamond Grade | 400+ cd/lx/m² | 10-12 years | Expressways |
| Type IX | Diamond Grade | 600+ cd/lx/m² | 12+ years | Critical zones |
Base Materials
| Material | Thickness | Best For |
|---|---|---|
| Aluminum Alloy 1050/3105 | 1.0mm - 3.0mm | Standard road signs |
| Aluminum Composite Panel | 3mm - 4mm | Large signs |
| Mild Steel (GI/Color Coated) | 1.6mm - 3.15mm | Heavy-duty applications |
| Stainless Steel 304 | 1.0mm - 2.0mm | Premium/corrosion-prone areas |
Color Specifications
| Color | Pantone Reference | Usage |
|---|---|---|
| Red | 485 C | Stop, prohibition borders |
| Blue | 2945 C | Mandatory signs background |
| Yellow/Golden | 116 C | Warning elements |
| White | - | Text, symbols, backgrounds |
| Black | - | Symbols, text |
| Green | 348 C | Directional signs |
Indicative Pricing (per sign)
*Bulk order discounts available for quantities above 50 units
| Sign Type | Standard Size | Engineering Grade | High Intensity | Diamond Grade |
|---|---|---|---|---|
| Stop Sign | 600mm | ₹450-550 | ₹750-900 | ₹1,200-1,500 |
| Speed Limit | 600mm | ₹400-500 | ₹650-800 | ₹1,000-1,300 |
| No Entry | 600mm | ₹400-500 | ₹650-800 | ₹1,000-1,300 |
| Give Way | 600mm | ₹400-500 | ₹650-800 | ₹1,000-1,300 |
| One Way | 600x450mm | ₹450-550 | ₹700-850 | ₹1,100-1,400 |
Frequently Asked Questions
Find answers to common questions about our regulatory signs
According to IRC:67-2012, stop signs for national highways should be 900mm in side width (octagonal). For state highways, 750mm is recommended, and for urban/local roads, 600mm is the standard size.
